Replaying 2.7 Million Honeypot Attacks: From GitHub Gist to Interactive Map

▸ See it live: kyhomelab.github.io/honeypot-attacks — interactive replay of 527 IPs, 2.7M attempts, 37 days of capture.

A few months ago I built a Cloud-to-Ground Honeypot on Azure. It captures real RDP attacks, runs them through n8n SOAR workflows, and publishes a public threat feed as a GitHub gist that updates hourly. By the time I came back to it, the gist had logged 2.7 million attempts from 527 unique attackers across 69 countries over a 37-day window.

That’s a lot of real signal sitting in a flat text file.

So I decided to do something with it: turn the static threat feed into an interactive map you can scrub through time, complete with a cyberpunk-neon theme to match my live homelab dashboard.

Here’s how it came together.

The data source — and one trick that unlocked everything

The gist itself is just a plain text file:

# Cloud Honeypot Threat Feed
# Generated: 2026-02-13T05:00:52.673Z
# Total Unique Attackers: 301

IP ADDRESS       | COUNTRY    | CITY         | ATTACK VOLUME
----------------------------------------------------------------------
37.187.24.235    | France     | Roubaix      | Attempts: 119589
5.181.86.102     | Ukraine    | Unknown      | Attempts: 49015
...

n8n overwrites this file every hour with the latest aggregated state. Useful, but only the latest snapshot is exposed via the gist’s “Raw” URL — you can’t see what the file looked like yesterday.

Here’s the trick: gists are git repositories. Every revision is a real commit. The browser UI shows recent revisions; the GitHub API caps history at 30; but if you git clone the gist directly, you get all 800 commits going back to the day n8n first started publishing.

git clone https://gist.github.com/kyhomelab/eb6f58df93df4ea994b1a2a66d8610e6.git honeypot-gist
cd honeypot-gist
git log --oneline | wc -l
# 800

That’s the difference between a static threat feed and a 37-day time series.

Parsing the timeline

For each commit, I needed to extract the file content and find the first revision in which each IP appeared — that’s the “first seen” timestamp for the replay.

log = subprocess.check_output(
    ["git", "-C", WORK, "log", "--reverse", "--pretty=format:%H|%cI", "main"],
    text=True
).strip().splitlines()

ips = {}
for sha, ts in (line.split("|", 1) for line in log):
    body = subprocess.check_output(["git", "-C", WORK, "show", f"{sha}:honeypot_blocklist.txt"], text=True)
    for line in body.splitlines():
        m = LINE_RE.match(line.strip())
        if not m: continue
        ip = m.group(1)
        if ip not in ips:
            ips[ip] = {"first_seen": ts, ...}

Walk all 800 commits, keep the earliest ts per IP. Done. 527 unique attackers across the full window.

GeoIP enrichment

The gist already had country and sometimes city — but not lat/lon, which Leaflet needs to render markers. I batched the IPs through ip-api.com (free, no API key, 100 IPs per request, 15 requests/min limit):

payload = json.dumps([
    {"query": ip, "fields": "query,country,countryCode,city,lat,lon,as,asname,status"}
    for ip in batch
]).encode()
req = urllib.request.Request("http://ip-api.com/batch", data=payload)

527 IPs across 6 batches with 4.5-second sleeps. ~30 seconds total, fully automated, fully free.

Output: a single honeypot-attacks.json file with everything the page needs — committed alongside the HTML so the dashboard is fully self-contained, no backend, no API keys, no recurring infrastructure cost.

Building the map

Stack:

• Leaflet for the map engine — free, open source, mature
• CartoDB Dark Matter as the basemap — pure dark grayscale that lets the neon pins pop
• Leaflet.markercluster for dense regions (cyan-bordered cluster bubbles with magenta count labels)
• Leaflet.heat for the optional density heatmap layer
• Vanilla JavaScript for state management — no framework, no build step

Each pin is a circleMarker sized logarithmically by attempt count:

const radius = Math.max(4, Math.min(18, Math.log10(Math.max(a.attempts, 1)) * 3));

Smallest pin: a single-attempt drive-by. Largest: a single attacker that tried 120,000 times.

The replay slider

The whole point of a 37-day dataset is to see how it built up. So I added a time slider with play/pause/speed controls:

• Drag → instantly recompute everything at that point in time (filter pins, recount stats, reshuffle bar charts)
• ▶ Play → auto-advance through the timeline
• Speed selector → 100s / 20s / 10s / 4s / 2s for full replay

For each tick, the script filters markers where m._ts <= cutoff, totals attempts, and updates the country/ASN bar charts and the four big stat tiles. Five hundred markers re-rendering at 10 Hz turned out to be smooth even on mobile — Leaflet’s chunkedLoading cluster mode does most of the work.

Cyberpunk neon

Same palette as my Grafana dashboard: cyan #00F5FF, magenta #FF00AA, electric yellow #FFFF00, neon green #00FF9F. The header title uses an animated gradient that shifts through all three colors on a six-second loop:

.attack-page h1 {
  background: linear-gradient(90deg, #00F5FF 0%, #FF00AA 50%, #FFFF00 100%);
  background-size: 200% auto;
  -webkit-background-clip: text;
  -webkit-text-fill-color: transparent;
  animation: flow 6s linear infinite;
}
@keyframes flow {
  0%, 100% { background-position: 0% 50%; }
  50% { background-position: 100% 50%; }
}

Stat tiles glow in their semantic color (text-shadow: 0 0 20px currentColor). The slider thumb has a cyan halo. Cluster bubbles glow magenta over a cyan base.

The visual extras

Three optional layers turned the page from “static map with a slider” into something that actually feels like a threat-intel platform:

🔥 Heatmap toggle. Switches from discrete pins to a density gradient running cyan → green → yellow → magenta → hot red. Same data, dramatically different viewpoint — at world zoom you immediately see the attack hotspots in Eastern Europe, Russia, and parts of Asia.

📡 Attack arcs. When the slider plays forward and a new IP first appears, a magenta polyline arcs from the attacker’s location to the honeypot’s pin (Azure East US — Virginia, geographic equivalent at 37.43, -78.66). Each arc is a quadratic bezier with a control point above the midpoint:

const midLat = (lat0 + lat1) / 2 + Math.min(35, dist * 0.4);

The arcs animate via CSS — stroke-dasharray: 1000, stroke-dashoffset: 1000 paired with a keyframe that drives the offset to 0, giving the line a “drawing in” effect over 1.2 seconds, then a 2-second fade.

🎯 Target marker. A pulsing pin at the honeypot’s location with two concentric rings expanding outward in a 2-second loop. Pure CSS — box-shadow and transform: scale() keyframes.

The disasters

A few problems I tripped over and one I deserved:

The page rendered the homepage. First time I visited the live URL, instead of seeing my map I saw the entire homepage — hero section, certifications, projects, the works. Took me ten minutes to figure out: my page used layout: default, and on this Jekyll theme default statically includes the homepage sections and ignores the page’s own content. Switched to layout: page and it rendered properly.

Jekyll’s compress layout ate my JavaScript. All my // line comments got concatenated onto a single line during build, which means everything after // Map setup until the next semicolon got commented out. Page would load but nothing would render. The fix was moving the JS to an external /assets/js/honeypot-attacks.js file — Jekyll doesn’t process or compress assets in that path.

The play button did nothing. I clicked play and nothing happened. After staring at the code for a while I realized: the slider’s initial value is 100 (showing the full state by default). Clicking play tried to advance from 100, immediately tripped the next >= 100 end-condition, and silently called pause. Added a guard: if playing from end, snap back to 0 first.

The default speed was 26 minutes per replay. I’d anchored the playback math to the actual time window length (37 days). At “20x” speed, full replay would have taken 26 minutes of wall-clock time. Rebased to “% slider movement per real second” so the dropdown options now mean what they say: 100 seconds, 20, 10, 4, or 2.

The pie charts said “Value” four times. Each piechart segment showed up in the legend as “Value” because Grafana doesn’t auto-translate legendFormat to the field’s display name on multi-target panels. The fix was overrides keyed by byFrameRefID:

{
  matcher: { id: "byFrameRefID", options: "A" },
  properties: [{ id: "displayName", value: "Virtual Machines" }]
}

(Wait — that was the dashboard. Same lesson, different page.)

Navbar got eaten by Leaflet. When you scrolled past the map, the map’s tile pane rendered over the fixed navbar. Leaflet uses internal z-index up to ~800 for its panes; Bulma’s fixed navbar defaults to 30. Bumped the navbar to 1100 (scoped to this page only) and the stacking order behaved.

The grey box around gradient text. When I added background-clip: text to the gradient row dividers in the dashboard, every styled element grew a grey rectangle around it. Took a frustrating debug session to figure out: background-image: linear-gradient(...) doesn’t reset the element’s background-color, so the inherited grey from default styling was filling everything outside the text glyphs. One line fix: background-color: transparent !important.

What it demonstrates

The technical surface I wanted to show with this page:

• Reading non-obvious sources — gists are git repos, history is queryable, time series can be reconstructed from “just” a flat file
• Light data engineering — git log walking, regex parsing, dedup-by-first-seen, GeoIP batch enrichment
• Frontend data viz — Leaflet, marker clustering, heatmaps, animated SVG paths, time-bounded filtering
• Performance-aware UX — 500-marker filtering at 10 Hz, capped simultaneous arc rendering, mobile-optimized breakpoints
• Production-grade hosting — fully static, no backend, no API keys, no costs, served by GitHub Pages with no rebuild needed when n8n updates the gist

What’s next

A few directions worth considering:

• Per-IP attempt timeline — click a pin to see how that attacker’s attempt count grew across the 800 revisions (mini sparkline)
• AbuseIPDB enrichment — lookup confidence score for each IP, color-code pins, add a “show only IPs with >75% confidence” filter
• Reverse DNS / PTR records — adds character to popups (*.contabo.host tells a story)
• Country choropleth layer — fill country shapes by attack volume for a complementary global view
• Live updating — fetch the gist’s latest revision client-side so the page auto-reflects new attacks without a republish

For now, the static snapshot is what I have. Open the live page, click ▶ PLAY, and watch a month’s worth of attacks build up over twenty seconds.

Most fun I’ve had with a frontend project in a long time.
